Types of Pallets
1. Types Based on Usage and Structural Design for Customers
Stringer Pallet
Uses long stringers to support the deck boards.
Stringers are placed parallel to the direction of use.
Easy to lift with a forklift from both sides.
Can add 4-way entry by cutting notches in the stringers.
Block Pallet
Uses blocks or cubes for support instead of stringers.
Designed to be stronger and more durable than stringer pallets.
Can be lifted with a forklift from all four directions (4-way entry).
Suitable for applications requiring high strength.
Double-Face Pallet
Has deck boards on both the top and bottom.
Can be used on both sides.
Suitable for applications requiring better weight distribution.
Single-Face Pallet
Has deck boards only on one side.
Suitable for general use and transportation where flipping the pallet is not required.
Reversible Pallet
Designed to be fully usable on both sides.
Suitable for applications requiring quick pallet rotation.
2. Types Based on Standard Sizes
ISO Standard Sizes (International Organization for Standardization):
1200 x 1000 mm (47.2 x 39.4 inches)
Static Load: approximately 4000 kg
Dynamic Load: approximately 1000-2000 kg
Racking Load: approximately 500-1000 kg
1200 x 800 mm (47.2 x 31.5 inches) (EURO pallet)
Static Load: approximately 4000 kg
Dynamic Load: approximately 1500-2000 kg
Racking Load: approximately 500-1000 kg
1200 x 1200 mm (47.2 x 47.2 inches)
Static Load: approximately 3000 kg
Dynamic Load: approximately 1000-1500 kg
Racking Load: approximately 500-800 kg
North American Standard Pallet Sizes:
48 x 40 inches (1219 x 1016 mm) (GMA pallet)
Static Load: approximately 3000-4000 lbs (1360-1814 kg)
Dynamic Load: approximately 2500 lbs (1134 kg)
Racking Load: approximately 1000 lbs (454 kg)
42 x 42 inches (1067 x 1067 mm)
Static Load: approximately 3000 lbs (1360 kg)
Dynamic Load: approximately 2500 lbs (1134 kg)
Racking Load: approximately 1000 lbs (454 kg)
48 x 48 inches (1219 x 1219 mm)
Static Load: approximately 3000 lbs (1360 kg)
Dynamic Load: approximately 2500 lbs (1134 kg)
Racking Load: approximately 1000 lbs (454 kg)
Asian Standard Pallet Sizes:
1100 x 1100 mm (43.3 x 43.3 inches)
Static Load: approximately 3000 kg
Dynamic Load: approximately 1000-1500 kg
Racking Load: approximately 500-800 kg
1100 x 1100 mm (43.3 x 43.3 inches) (Japan)
Static Load: approximately 4000 kg
Dynamic Load: approximately 2000 kg
Racking Load: approximately 1000 kg
Load Considerations
Static Load: The maximum weight a pallet can support when stationary on the floor.
Dynamic Load: The maximum weight a pallet can support while being moved (e.g., lifted by a forklift).
Racking Load: The maximum weight a pallet can support when placed on a storage rack.
